Canon imagePROGRAF iPF770 36" Colour Large Format Printer


Already own this? Tell us what you think... Review This Product
Key Features
Back Key Features
  • Up to 0:48 min A0 Colour Print
  • Up to 0:48 min A0 Mono Print
  • USB & Network
  • 2,400 x 1,200 dpi Print
  • 256MB RAM
  • Windows & Mac Compatible
  • GARO (Graphics Arts Language with Raster Operations) HP-GL/2, HP RTL
Call for Price
28 In Stock
FREE Next Day Delivery*
Order in the next 10 hours, 49 minutes
for Free Delivery tomorrow 17th October
30+ trained printer experts
waiting to speak to you
0800 840 1992 call us FREE Mon - Fri 8:30am - 6:00pm
  • Overview
  • Cartridges & Accessories
  • Q & A
  • Reviews
Canon imagePROGRAF iPF770
  • Product Overview
  • Cartridges & Accessories
  • Questions & Answers
  • Reviews
Product Overview

Canon imagePROGRAF iPF770 in More Detail

Designed and developed specifically for larger print jobs, the ImagePROGRAF iPF770 can help in the creation of large marketing materials and brochure pieces. The A0 printer offers print solutions of a continually high standard – producing vibrant colour prints.Perfect for professional CAD, GIS and design environments, the printer can ensure the workplace’s output is of a consistently high standard. For industries in which accuracy is king, the ImagePROGRAF iPF770 can accommodate the important printing requirements.

5 Colour Ink System

To help you create incredibly realistic prints, Canon have implemented a 5 colour ink system in the ImagePROGRAF iPF770. The new magenta ink included as part of the Lucia ink system helps add vibrancy and accuracy to all prints – boasting the ability to create a broader number of tones and colours.

Cloud Printing

Ideal for large print jobs, the ImagePROGRAF iPF770 boasts cloud printing functionality allowing users to store large files remotely and then complete print tasks from almost anywhere. This is particularly well suited to printing huge files which require large amounts of storage space and memory.

Quick Print Design

The fast carriage speed of the streamlined ImagePROGRAF iPF770 allows for speedier creation and completion of large print tasks. Helping your workforce create a higher quantity of work, the printer never compromises the quality of the output.

What's in the Box?

What's in the Box?

  • 1 x print head
  • AMYK MBK 90ml starter inks
  • 3 inch core adapters
  • set up guide
  • user software CD
  • Safety leaflet
  • PosterArtist Lite leaflet
  • PosterArtist Lite software CD
  • EAC leaflet
  • Quick Guide
Detailed Specification

Detailed Specification


Speed Colour Up to 0:48 min A0 Colour Print
Speed Monochrome Up to 0:48 min A0 Mono Print
Product Group Output 36"
Printer Resolution 2,400 x 1,200 dpi Print


Interface Type(s) USB & Network

System Specification

Memory (Maximum) 256MB RAM


Operating Systems Supported Windows & Mac Compatible
Compatible Operating Systems 32 bit – Windows XP, Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows Server 2003 / 2003R2, Windows Server 2008 64 bit – Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows Server 2003 / 2003R2, Windows Server 2008 / 2008R2, Windows Server 2012 / 2012R2 Mac: OSX – 10.6.8 - 10.10.x

Media Handling

Borderless Printing 10” (254 mm), B4 (257 mm), A3 (297 mm), Banner (300 mm), 14” (356 mm), A2 (420 mm), A2+/17” (432 mm), B2 (515 mm), A1 (594 mm), 24” (610 mm), B1 (728 mm), A0 (841 mm), 36” (914 mm)
Maximum Paper Weight 0.07 - 0.08mm
Media Sizes Supported Roll Paper: Width (254 - 914.4mm) x Length (203.2mm - 18m) Cut Sheet: Width (203.2 - 914.4mm) x Length (279.4mm - 18m)
Roll Diameter 150.0 mm
Roll Length 18 m (Varies according to the OS and application)

Barcodes & Labels

Barcode 4549292020045


Mono or Colour Printer Colour
Technology Large Format Printer
Dimensions 1304mm(w) x 887mm(d) x 1062mm(h) - 64.6kg
Noise Level Operation: approx. 48 dB Standby: 35 dB or less Accoustic Power: 6.5 Bels Based on ISO 7779
Power Consumption Operation: 140 W or less Power Off Standby: 0.5 W or less
Printer Type 5 Colour - 36" / 914.4mm
Product Type Large Format Printer

Consumable Info

Ink Type inkjet on demand 6 colours integrated (6 chips per printhead)
Number of Nozzles Total: 15,360


Printer Languages GARO (Graphics Arts Language with Raster Operations) HP-GL/2, HP RTL

In the Box

In The Box 1 x print head, AMYK MBK 90ml starter inks,3 inch core adapters, set up guide, user software CD, Safety leaflet, PosterArtist Lite leaflet, PosterArtist Lite software CD, EAC leaflet, Quick Guide
